Scope of application
This series of voltage stabilizers will not produce any interference signals and are suitable for various equipment and places. For example: factory-wide voltage stabilizing equipment, SMT equipment, CNC equipment, color printing equipment (Roland, Heidelberg, Highburg), precision instruments, medical equipment, high-speed rail tunnels, industrial and mining sites, etc.
Working principle
Transportation and storage
1. The intelligent non-contact induction voltage regulator/non-contact voltage stabilizer should be protected from rain and severe vibration during transportation or loading and unloading. During night transportation, a tent should be used to cover it to avoid moisture.
2. The intelligent non-contact induction voltage regulator/non-contact voltage stabilizer must be kept in a place with good air circulation, no rain or snow intrusion, and the surrounding air temperature should not be higher than +40℃, not lower than -10℃, and the relative temperature should not be greater than 85% and In a warehouse where no chemically corrosive gases or media exist.
3. Unpack and inspect once every six months to check whether the parts are rusty and whether the lubricating oil and cooling oil have deteriorated to improve storage conditions.
Overall dimensions
The product must be installed indoors, usage environment and precautions
●The altitude does not exceed 1000 meters
●Ambient temperature
Maximum temperature +40℃
Maximum daily average temperature +30℃
Maximum annual average temperature +20℃
Minimum temperature -5℃;
●The waveform of the power supply voltage is similar to a sine wave
●The installation site should be free of gas, steam, dust, chemical deposits of dirt and other explosive and corrosive media that would seriously affect the insulation of the voltage regulator.
●The installation site should be free of severe vibration and bumps.
●Parallel operation is not possible.
Installation steps
1. Intelligent non-contact induction voltage regulator/non-contact voltage stabilizer terminal block
On the input end of the voltage regulator, uppercase letters (A, B, C) are posted for the input terminal connections. At the output end, where the current transformer is connected, lowercase letters (a, b, c load) are posted for the output connections. There are ( 0 line) is connected to the zero line terminal.
2. Connect the input and output cables to the corresponding terminals. After confirming that the connection method is correct and the tightening screws are not loose, the installation is complete.
3. For the control system, please press the TWK168-B microcomputer intelligent control system provided by our company. Voltage regulator controller is used for operation.
